3600 SERIES USER MANUAL
3600 Series Programmable DC Power Supply
VERSION 2.10 2006.03
12
BaudRate=4800
BaudRate=9600
BaudRate=19200
BaudRate=38400
Select the Baud Rate by using the UP and DOWN keys or the rotary
knob, then press “Enter” for confirmation.
2.3.7 Setting communication address (0~31)
This function is used to set the address of the power. To communicate with the computer or other equipment, the
3600 power supply must be assigned an address.
When you select “Address Set” function, the LCD will display:
Address Set=**
New=
Set the address by using the number keyboard or the rotary knob, and
then press “Enter” for confirmation. The valid address range is from 0 to
31.
2.3.8 Key Lock
This function is used to lock the keyboard to keep the 3600 from unauthorized operation. Only the person with the
correct password is allowed to operate the power supply. Select the “Key Lock” function, the LCD will display:
Enter Password Enter a 4 numbers password, then press “Enter” to confirm.
2.3.9 Clear saved data
This function is to clear the parameters stored in the 3600’s nonvolatile memory.
When you select “Clear Save Data” function, the LCD will display:
Clear * Enter the memory address you want to clear, then press the “Enter” key.
2.3.10 Load Default
This function is to restore all the parameters to the factory setting.
Select “Load Default” function, the LCD will display:
Don’t Load
Load Default
Select “Load Default”, and press “OK” to restore to the factory
setting.
2.3.11 Exit
Select “Exit” to exit the menu operation.
To Next Page
