Overview
12
Overview
Spigot
Fuse holder
Focus knob
Connector panel
Tilt lock lever
Stirrup bracket
Stirrup
PowerCON connector
Fixture menu
Top latch
Safety catch
Handle
(depending on version)
Front view and back view, manual version
