Arris BDA Series - Specifications

485855-001 Rev B Installation Instructions 7
Figure 4 illustrates a remote power installation.
Figure 4
Remote power
installation
Specifications
The following specifications apply to the BDA-S* drop amplifier:
Table 1 BDA-S* specifications
Forward Path Value
Passband (MHz) 52 through 1000
Gain (dB)
BDA-S1 14.0 minimum, 15.0 nominal
BDA-S2 10.2 minimum, 11.0 nominal
BDA-S4 6.4 minimum, 7.0 nominal
Input return loss (dB) 18.0 minimum, 23.0 nominal
Output return loss (dB) 18.0 minimum, 23.0 nominal
Flatness (dB) ±0.8 maximum
Noise figure (dB) 2.5 dB nominal, 3.0 maximum
