Arrma Voltage - Other Battery Types; NiMH Mode; LiPo Mode

© 2017 ARRMA Durango Ltd. A subsidiary of Hobbico, Inc.
Other Battery Types
Battery Size
Required (MAX)
Chemistry Required
Min mAh Capacity
Required
Nominal
Voltage
Minimum Continuous
Discharge Current
18650 (18 x
67.5mm) Min of 2
Lithium Manganese Nickel (INR)
Lithium Manganese Oxide (IMR)
1500mAh +
7.4V
(2x3.7V)
20A
6 Cell Stick NiMH
(48x141x26mm)*
Nickel Metal Hydride (NiMH) 2000mAh + 7.2V n/a
2S Stick LiPO
(48x141x26mm)*
Lithium Polymer (LiPO) 2000mAh + 7.4V 25C
POWER LED = GREEN
NiMH MODE LiPO MODE
POWER LED = YELLOW
! !
*Maximum size available in battery compartment to t battery and associated wiring
11
