Arrow EN86-A - Parts List

Parts List
B12
12
Assembly Part Part Quantity Check
Key No. Number Description in Carton List
1 6615 Rear Wall Angle 2
2 6617 Door Track Splice 1
3 10498 Horizontal Door Brace 4
4 6658 Gable Brace 2
5 7875 Roof Panel 4
6 7906 Right Gable 2
7 7907 Left Gable 2
8 8461 Ridge Cap 1
9 8466 Right Roof Panel 2
10 8467 Left Roof Panel 2
11 8474 Roof Beam 3
12 8476 Side Wall Angle 3
13 9920 Side Wall Channel 2
14 8482 Side Roof Trim 2
15 8941 Ramp 1
16 8946 Side Floor Frame 2
17 8995 Wall Panel 4
18 9355 Vertical Door Brace 2
19 10488 Right Door 1
20 10488 Left Door 1
21 9363 Wall Panel 2
22 9900 Door Jamb 2
23 9924 Rear Wall Channel 2
24 9377 Rear Floor Frame 2
25 9378 Door Track 2
26 9379 Front Floor Frame 2
27 9380 Front Corner Panel 2
28 9384 Rear Corner Panel 2
