The gables go on top of the front and
rear walls to support the roof beams.
NOTE
The gables are packed nested
together and might be mistaken
as one piece. Carefully separate
them before continuing.
1 Attach the four roof beam brack-
ets to the gables using two bolts,
washers and nuts.
NOTE
Mounting leg of bracket must
face toward center of gable
Step 10
B23
● Parts Needed For ●
Gable Assemblies
●●
●●
● 7906 Right Gable (2)
●●
●●
● 7907 Left Gable (2)
●●
●●
● 7916 Roof Beam Bracket (4)
7907
Washer
Roof Beam Brackets
7916
7906
FRONT
1
STEP
To Next Page
