Arrow LW108 - Page 28

28
(QTY: 56)
Front Chan.
2
9365
Assemblies from Step 2:
• Rear Wall Channel Assembly (1)
• Side Wall Channel Assemblies (2)
You will need for this page:
Insert screw where
Channels meet.
Step 10: Wall Channels
Install Rear Wall Channel by placing screws
through all remaining holes in Wall Panels.
1
3
Install Front Wall Channels by placing
screws through all remaining holes in Wall
Panels. Insert a screw in both rear corners
where Side and Rear Wall Channels meet.
2
Install Side Wall Channels by placing screws
through all remaining holes in Wall Panels.
Install Channels on inside of building.
28A
