Example displays are shown below:
Main Display: Both Small
Main Display: Laser Large
Main Display: TEC Large
Main Display: Both Large
Measurements
One of the advantages of the ComboSource is its ability to display both the set
point and measurements simultaneously (when in small display mode). The
table below shows which values will appear on the display depending on the
mode selected:
IoSET= 3850.1mA .LoBW.
Im=950.1µA Vf=1.941V
TSET= 25.00°C V= 6.72V
T= 25.00°C I= 3.25A
Io= 3850.1
TSET= 25.00°C V= 6.72V
T= 25.00°C I= 3.25A
IoSET= 3850.1mA .LoBW.
Im=950.1µA Vf=1.941V
T= 25.00
Io= 3850.1
T= 25.00
