Art-Tech ASK-21 - Radio Control System Operation; R;C System Components; Receiver Connection Diagram

If the parts o f the ASK-21 Glid er were
damaged, please contact the dealer to purchase
new components.
Notes
8
Operating Manual for the radio control system
Components to the R/C system
a transmitter, a receiver, a servo, a speed controller
The sketch map for connecting the receiver:
RECEIVER
ER61-2.4GHz
CH
ESC
Rudder servo
Elevator servo
Left aileron
servo
Right aileron
servo
RECEIVER
ER61-2.4GHz
CH
Signal
(White line)
(Red line)
(Black line)
Motor
Battery
