12. TECHNICAL DATA
TECHNICAL DATA UNITS APOLLO APOLLO AIR
*Global heat rating(efficiency)
Kcal/h
Kw
11610
13,5
12040
14
Hourly fuel consumption Kg/h 3,5
Global efficiency % 80,2 83,1
Smoke temperature °C 262 256
Emissions of CO (at 13% of O2) % 0,15 0,14
Performance range (min-max) Kw 6,5 - 21.0
Fuel - Wood, Briquette
Burner dimensions ( W x D x H ) cm 33 χ 33 χ 45
Flue draught Pa 12(±2)
Recommended hourly consumption
on fire wood
Kg/h 1,8 - 5,3
Heatable surface m
2
95 100
Weight kg 144 - 212 151 - 219
External air intake. Its section must
be increased 20% for each additional
meter after the 1metre
cm Ø 10
Smoke outlet diameter cm Ø 15
Stove suitable for rooms of no less
than
m
2
35
*The stove works with intermittent combustion. Intermittent combustion in this context means normal
use of the wood stove, i.e. fuel is added as soon as the fuel has burnt down to a suitable amount of
embers.
Flue Diameter (cm) Height (cm)
The inside section of the flue must be increased
10% for each 500m in altitude above sea level.
Ø 15 ≥ 400
Ø 20 ≥ 350
13. WARRANTY
We grant a two year warranty for your new ARTE
®
wood stove. The warranty period begins on the day the
stove is installed and tested by the specialized dealer. We also grant a one year warranty for all the electrical
parts (if any are installed).
Warranty claims become valid when the purchase price for the stove has been paid in accordance with the
agreement and the warranty certificate has been completed and returned within thirty days to ARTE
®
G.
Karnoutsos & CO.
If one of these conditions is not fulfilled the minimum warranty of six months applies.
13.1 Warranty terms
> Proper installation by a specialized dealer
> The wood stoves are handled in accordance with these operating instructions
> No continuous firing
> No overheating
> Regular maintenance / cleaning (once a year)
> There must be no modifications to the stove structure: these can cause malfunctions and permanent
damage
13.2 Excluded from the warranty
> Wearing parts like gaskets, cast grate, fireclay, and glass
> Smoke and soot damage
> Natural discoloration or deviating colors on the outer cladding
> Cracks in the combustion chamber that have no effect on the safe functioning of the ARTE
®
wood stove
> Damage incurred through failure to observe these operating instructions
> Damage covered by an insurance policy or other agreement
13.3 Responsibility
Upon delivery of this manual ARTE
®
declines all liabilities, both civil and penal, for any accidents that may
derive from the total or partial failure to comply with the specifications contained in it.
ARTE
®
also declines all responsibility resulting from an improper use of the appliance, incorrect use by the
user, from unauthorized alterations and/or repairs, or the use of non-original or non-specific spare parts
for this particular stove.
13.4 Extraordinary maintenance
Extraordinary maintenance on the stove model to which this manual refers, must be carried out by qualified
personnel.
13.5 Responsibility for installation
It is not the responsibility of ARTE
®
to carry out the work needed to install the stove. Such works are entirely
up to the installer who is requested to check the flue and air intake and to check if the installation solutions
proposed are feasible. All applicable standards and local, national and European legislation in force in the
country where the stove is installed must be respected.
50 | 51
APOLLO WOOD STOVE
