Arthrex AR-3200-0001T User Manual

950-0027-01B 16 of 55
Figure 3-AR-3210-0001 3 CCD Camera Head with Integrated Optics
1.9.3 AR-3210-0001 Camera Head with Integrated Optics
1. Button 1 — A programmable button
that can activate various functions of the
camera. See “Optional Tablet Data Input
Device” for programming information.
2. Button 2 — A programmable button
that can activate various functions of the
camera. See “Optional Tablet Data Input
Device” for programming information.
3. Focus Ring — Used to sharpen, or
bring into focus, the image detail.
4. Grasping Mechanism — Accepts and
locks into place the compatible scope.
DIN 58105 compliant endoscope
interface.
