950-0027-01B 17 of 55
Figure 4-AR-3210-0003 [C-MT], AR-3210-0004 [C-MT, 20 Foot]
Figure 5-AR-3210-0007 [C-MT, Zero Angle]
1.9.4 C-Mount Camera Heads
1. Button 1 — A programmable button
that can activate various functions of the
camera. See “Optional Tablet Data Input
Device” for programming information.
2. Button 2 — A programmable button
that can activate various functions of the
camera. See “Optional Tablet Data Input
Device” for programming information.
3. C-Mount Threads — Accepts standard
C-Mount Optical Couplers.
