8 Aruba 530 Series Campus Access Points | Installation Guide
Access Point Installation
The Aruba 530 Series access points are designed for ceiling or wall-mounted deployments
Software
Aruba 530 Series requires ArubaOS or ArubaInstant 8.6.0.0 or later.
For instructions on choosing operating modes and initial software configuration, refer to the Access Point
Software Quick Start Guide.
Verifying Post-Installation Connectivity
The integrated LED on the access point can be used to verify that the access point access point is receiving power
and initializing successfully (see Table 1 and Table 2). Refer to the Access Point Software Quick Start Guide for
further details on verifying post-installation network connectivity.
Electrical and Environmental Specifications
For additional specifications on this product, please refer to the product data sheet at www.arubanetworks.com/
products/networking/access-points/.
Electrical
Ethernet:
Eth0: 100/1000/2500/5000 Base-T auto-sensing Ethernet RJ45 interface
Eth1: 100/1000/2500/5000 Base-T auto-sensing Ethernet RJ45 interface
IEEE 802.3u (100 Base-T). IEEE 802.3ab (1000 Base-T), IEEE 802.3bz (2500/5000 Base-T)
Power over Ethernet IEEE 802.3bt or 802.3at 56V DC (nominal)
Power:
48V DC power interface, support powering through AC-to-DC power adapter (AP-AC-48V36C)
Maximum power consumption (excluding USB): Refer to datasheet
All Aruba access points should be professionally installed by an Aruba-Certified Mobility Professional (ACMP).
The installer is responsible for ensuring that grounding is available and meets applicable national and electrical
codes. Failure to properly install this product may result in physical injury and/or damage to property.
Tous les points d'accès Aruba doivent impérativement être installés par un professionnel agréé. Ce dernier doit
s'assurer que l'appareil est mis à la terre et que le circuit de mise à la terre est conforme aux codes électriques
nationaux en vigueur. Le fait de ne pas installer correctement ce produit peut entraîner des blessures
corporelles et / ou des dommages matériels.
For indoor use only. The access point, AC adapter, external antennas, and all connected cables are not to be
installed outdoors. This stationary device is intended for stationary use in partly temperature controlled
weather-protected environments (class 3.2 per ETSI 300 019).
Aruba access points are classified as radio transmission devices, and are subject to government regulations of
the host country. The network administrator(s) is/are responsible for ensuring that configuration and operation
of this equipment is in compliance with their country’s regulations. For a complete list of approved channels in
your country, refer to the Aruba Downloadable Regulatory Table at www.arubanetworks.com/techdocs/DRT/
Default.htm.
If a power adapter other than the Aruba-approved adapter is used in the US or Canada, it should be NRTL listed,
with an output rated 48V DC, minimum 0.75A, marked “LPS” and “Class 2,” and suitable for plugging into a
standard power receptacle in the US and Canada.
