2 Aruba 570 Series Outdoor Access Points | Installation Guide
Hardware Overview
Figure 1 AP-574 Front View (with Aesthetic Cover)
Figure 2 AP-574 Rear View (with Aesthetic Cover)
The antenna connectors of AP-574 are covered by an aesthetic cover. The aesthetic cover can be removed
when necessary.
USB Console Port
& Reset Button
System LED
E1
Grounding Point E0
