Aruba Instant On AP15 Access Point | Installation Guide 9
Figure 11 Instant On Portal Login Screen
Electrical and Environmental Specifications
Electrical
Ethernet:
One 100/1000 Base-T auto-sensing Ethernet RJ45 interface
Power over Ethernet IEEE 802.3at 56VDC (nominal) and 802.3af 48VDC (nominal).
Power:
Direct DC source: 12Vdc nominal, +/- 5%
Power over Ethernet (PoE): 802.3at and 802.3af complaint source
Environmental
Operating:
Temperature: 0°C to +50°C (+32°F to +122°F)
Humidity: 5% to 93% non-condensing
Storage and transport:
Temperature: -40°C to +70°C (-40°F to +158°F)
Humidity: 5% to 93% non-condensing
Regulatory Model Number
AP15 RMN: APIN0315
If a power adapter other than the Aruba-approved adapter is used in the US or Canada, it should be NRTL listed,
with an output rated 12Vdc, minimum 2A, marked “LPS” and “Class 2”, and suitable for plugging into a standard
power receptacle in the US and Canada.
For indoor use only. The access point, AC adapter, and all connected cables are not designed for outdoor use.
RF Radiation Exposure Statement: This equipment complies with RF radiation exposure limits. This equip-
ment should be installed and operated with a minimum distance of 13.78 inches (35cm) between the radiator
and your body for 2.4 GHz and 5 GHz operations. This transmitter must not be co-located or operating in con-
junction with any other antenna or transmitter.
