System Type System Type System Type System Type System Type System Type
HPP Options
Single Stage FF/C Multi Stage FF/AC Multi Stage Dual Fuel Single Stage HP W/Elec Multi Stage HP W/Elec Duel Fuel /w Inverter HP
F or C
Fahrenheit Fahrenheit Fahrenheit Fahrenheit Fahrenheit Fahrenheit
Priority
Automatic Automatic Automatic Automatic Automatic Automatic
Zone 1 Stat Type
Heat/Cool Heat/Cool HP or H/C HP or H/C HP or H/C HP or H/C
Zone 1 Weight
Default N/A set as needed set as needed Default N/A set as needed set as needed
Zone 2 Weight
Default N/A set as needed set as needed Default N/A set as needed set as needed
Zone 3 Weight
Default N/A set as needed set as needed Default N/A set as needed set as needed
Zone 4 Weight
Default N/A set as needed set as needed Default N/A set as needed set as needed
AH Stage Threshold
Default N/A set as needed set as needed Default N/A set as needed set as needed
Heat Stage
Default N/A Default N/A 88 88 88 80
Cooling Stage
Default N/A 55 55 Default N/A 55 55
Balance Point
Lock-in Lock-in 30 Default N/A Default N/A *Set as required*
Resistance Lockout
Default N/A Default N/A Default N/A Lock In Lock In *Set Equal to Balance Point*
HP High Limit
Default N/A Default N/A 120 120 120 120
Aux High Limit
140 140 140 140 140 140
Cooling Low Limit
42 42 42 42 42 42
Backup Fuel Type
Fossil Fuel Fossil Fuel Fossil Fuel Electric Electric Electric
Backup Control Fan
TRUE TRUE TRUE FALSE FALSE TRUE
Dehum Voltage
24 24 24 24 24 24
Secondary Purge
60 60 60 60 60 0
Dehum Cycle Time
set as needed set as needed set as needed set as needed set as needed set as needed
CON Lockout Temp
50 50 50 50 50 50
Rev Valve Energized
Default N/A Default N/A set as needed set as needed set as needed set as needed
Balance Point for Elec
FALSE FALSE FALSE set as needed set as needed TRUE
Demo Mode
FALSE FALSE FALSE FALSE FALSE FALSE
Color Legend
Must Be Set To
Suggested Set As Needed
Leave at Default, N/A
Inverter Heat Pumps are designed to run for an extended period and often lower supply temperatures, the HPP upstages to fossil fuel after 9 min run cycle if the "Heat Stage Threshold" is not met. Non standard
settings are needed to overcome this, the HPP needs to think there is an electric heater providing an OAT lock-out on W1 while still changing from heat pump to fossil fuel when meeting balance point where the heat
Balance point OAT and Resistance Lockout must be set to *same temperature*, Back-up Fuel Type Electric, and Balance Point for Electric True. This will keep the gas furnace from engaging during extended run
cycles but also provide an OAT change-over from heat pump to fossil fuel.
Suggested HeatPumPro Settings
To Next Page
