Arzel Heat PumPro - Ezy-Slide Damper Install cont.; Insert Damper Blade; Twist Damper into Position

Ezy-Slide Damper Install cont.
4. Twist into Position
Once the blade is inserted, rotate the damper 180 degrees with the tubing port facing the main duct
3. Insert the Damper
With the damper being held in the "Closed" position, insert with the blade at the wide end of the
triangle.
25
