AS MOTOR AS 800 FreeRider User Manual (English)

Questions and Answers:

J
juan87Aug 19, 2025
What to do if AS MOTOR AS 800 FreeRider Lawn Mower engine does not start?
- B
  Brandon GarzaAug 20, 2025
  If the engine doesn't start, check the following: * Ensure the fuel valve is open. * Refill the fuel tank if it's empty. * Close the choke. * If the device was tilted and oil leaked into the air filter, replace the air filter, unscrew the spark plug, start several times with the fuel valve closed, dry the spark plug, and screw it back in. * If the engine was flooded from too many start attempts, unscrew the spark plug, start several times with the fuel valve closed, dry the spark plug, and screw it back in. * Make sure the spark plug connector is attached. * If the air filter is dirty, clean it. * If the spark plug is sooted, damaged, or has an incorrect electrode gap, clean it and check the gap; replace if necessary.
C
Chad LoweryAug 22, 2025
Why AS MOTOR Lawn Mower engine starts badly or runs irregularly?
- D
  Dana SmithAug 22, 2025
  An engine that starts poorly or runs irregularly may be caused by: * An improperly closed choke. Open the choke. * A dirty air filter. Clean the air filter. * Poor quality, dirty, or old fuel. Always use fresh fuel. * Sooted, damaged spark plugs, or incorrect electrode gap. Clean the spark plugs and check the electrode gap; replace if necessary.
A
Alyssa RichardsonAug 25, 2025
Why AS MOTOR AS 800 FreeRider Lawn Mower starter does not turn?
- C
  Chris BauerAug 25, 2025
  The starter may not turn due to several reasons: * The safety switches are not activated. Ensure the drive lever is in neutral, the cutting height is in transport position, and the driver is in the seat to activate the seat contact switches. * The battery is empty because the ignition key was not in the “Off” position, or the standstill period was too long. Charge the battery. * The fuse is defective. Replace the fuse.
E
Edward MiddletonAug 26, 2025
Why AS MOTOR AS 800 FreeRider engine gets hot?
- K
  Kenneth LewisAug 26, 2025
  The engine may overheat if: * The ventilation grid is dirty. Clean the ventilation grid. * The oil level in the engine is too low. Refill engine oil.
A
Anne SchneiderAug 28, 2025
Why AS MOTOR AS 800 FreeRider Lawn Mower engine is smoking?
- K
  Keith OliverAug 28, 2025
  The engine may be smoking because: * The air filter is dirty or drenched with oil. Clean or replace the air filter. * The oil level is too high.
C
Catherine WagnerAug 30, 2025
Why AS MOTOR Lawn Mower has strong vibrations during operation?
- M
  Matthew ThompsonAug 30, 2025
  Strong vibrations during operation can be attributed to unbalance at the blade caused by incorrect sharpening or chips on the blade. Replace a damaged blade immediately.
K
Karen JacksonSep 1, 2025
What to do if AS MOTOR Lawn Mower device does not move?
- T
  Tanya RodriguezSep 1, 2025
  If the device does not move, it could be because: * The drive is unlocked. Lock the drive. * The hydrostat drive is overheated. Cool it down.
W
willie60Sep 3, 2025
Why AS MOTOR Lawn Mower uneven cut, lawn becomes unsightly?
- V
  vmurphySep 4, 2025
  An uneven cut and unsightly lawn can occur if: * The blade is dull or worn. * The speed is too high for the cutting height. Reduce speed and/or select the correct cutting height. * The mower housing is heavily soiled. Clean it. * There are different tire pressures. Check the tire pressures. * The mower housing is not parallel to the ground.
A
Andrea HernandezSep 5, 2025
Why AS MOTOR Lawn Mower mulching result with high plant material not satisfactory?
- C
  Christopher ScottSep 5, 2025
  If the mulching result is not satisfactory with high plant material, it may be because the speed is too high. Reduce speed.
M
Marc ThompsonSep 7, 2025
Why AS MOTOR Lawn Mower mulching result with low plant material not satisfactory?
- A
  Alicia OlsenSep 8, 2025
  If the mulching result is not satisfactory with low plant material, it may be because the plant material is ejected too quickly. Increase speed.

AS MOTOR AS 800 FreeRider Specifications

General

Brand	AS MOTOR
Model	AS 800 FreeRider
Category	Lawn Mower
Language	English

Summary

Operating Instructions

Preface

Intended Use

Prohibited Uses

Lists prohibited uses and activities for the device to ensure safety and proper function.

Explanation of Symbols

Symbols in Instructions

Details symbols used within the operating instructions to denote dangers and procedures.

Symbols on Device

Describes symbols located on the device to inform users about potential hazards.

Type Plate

Manufacturer and Identification

Details about the manufacturer, device designation, and type.

Technical Specifications

Key technical data including power output, weight, and sound level.

Safety Instructions

Get Informed

Advice on reading instructions and familiarizing with the device.

User Restrictions

Defines who can operate the device and user limitations.

Fuel Safety

Guidelines for safe refueling and fuel storage to prevent fire and hazards.

First Aid

Procedures for immediate medical assistance in case of fuel exposure.

Measures in Case of Fire

Pre-Operation Checks

Personal Protective Measures

Required personal protective equipment for mowing operations.

Operational Safety Precautions

Caution When Mowing Slopes

Slope Operation Safety

Guidelines for safe operation on slopes, including angle limits and direction.

Slope Control and Stability

Ensuring stability and control on slopes through proper speed, braking, and parking.

Slope-Related Risks

Fire Hazard and Accessory Safety

Post-Operation and Maintenance Safety

Device Description

Control Elements

Front and Seat Controls

Details control elements like differential lock, fuel valve, and seat levers.

Braking and Blade Engagement

Operation of the foot brake, parking brake, and blade clutch lever.

Differential Lock Operation

Explanation of the differential lock mechanism and its operation.

Cutting Height Adjustment

Sitting Position

Ignition Lock

Drive Lever with Parking Brake

Drive/Idle Mode

Transport and Loading

Transporting the Device

Methods for transporting the device on pallets or ready for use.

Loading Procedures

Detailed steps and safety for loading the device onto a vehicle.

Assembly

Scope of Delivery and Unpacking

Details of package contents and steps for unpacking the device.

Mounting the Device

Information on Mowing

Pre-Mowing Checks and Preparation

Includes checking the area, personal protective measures, and preparing the mower.

Fueling and Seating Adjustment

Instructions for fueling the device and adjusting the seating position.

Checking the Oil Level

Starting the Device

Safety Requirements and Engine Start

Ensuring safety switches are active before starting the engine.

Blade Engagement and Disengagement

Instructions for blade engagement and disengagement during operation.

Driving Operations

Braking and Differential Lock

Using brakes and differential lock for control and stability.

Switching Off and Parking

Steps to safely shut down and park the device.

Maintenance Preparations

Device Cleaning and General Inspection

Instructions for cleaning the device and performing general inspections.

Brake System Checks

Procedures for checking the parking and foot brake functionality.

Lubrication Procedures

Blade Maintenance

Checking and Changing the Blade

When and how to replace the cutting blade based on wear.

Engine Maintenance

Oil Level and Spark Plug Checks

Procedures for checking engine oil level and spark plugs.

Air Filter Care

Guidance on cleaning or replacing the air filter for engine efficiency.

Checking and Charging the Battery

Hydrostat Transmission

Storing the Device

Storage and Restarting

Spare Parts, Wear Parts, and Accessories

Information on ordering parts, identifying wear items, and available accessories.

Disposal and Warranty

Troubleshooting Engine Start Issues

Starter and Engine Not Starting

Resolving problems related to the starter and engine not starting.

Troubleshooting Engine and Drive

Engine Performance and Movement Issues

Addressing issues with engine running, device movement, and blade engagement.

Blade Engagement and Rotation Problems

Diagnosing issues with blade engagement and rotation.

Troubleshooting Performance Issues

Vibrations, Noise, and Engine Heat

Resolving vibration, noise, and engine overheating problems.

Cut Quality and Mulching

Addressing causes for uneven cut and poor mulching performance.

Troubleshooting Operational Issues

Braking and Shut-off Problems

Resolving problems with the brake system and engine shut-off.

Other Operational Faults

Addressing mulching results and flat tires.

Technical Data: Engine and Drive

Technical Data: Cutting System

Technical Data: Dimensions and Weights

Technical Data: Capacities and Sound

Technical Data: Vibrations and Tires

Declaration of Conformity

Function and Standards

Defines the device's intended use and conforming standards.

Conformity Assessment

Information on the notified body and technical documentation.
