Device description
1
12
2
11
10
3
8
6
7
4
9
5
13
1 Fuel valve
2 Cutting height adjustment
(40 mm, 50 mm, 60 mm, 70 mm, 80 mm)
3 Air filter
4 Spark plug connector
5 Type plate
6 Guide bar with control elements
7 Bar release
8 Starter grip
9 Silencer
10 Ventilation grid
11 Tank filler spout
12 Oil filler opening
13 Cover
