9
10
Attach the desk frame to below desktop using 10 of ST4.8*25 screws, then attach the control box to below desktop using 2 of ST4.8*19 screws, at last attach the handset to
below desktop using 2 of ST3.5*19 screws.
Connect the the electric leg cables, handset cable, and power cord to the control box.
Assembly Instructions
ST4.8*25 Screw 2pcs
ST4.8*25 Screw 2pcsST4.8*25 Screw 2pcs
ST4.8*25 Screw 4pcs
ST4.8*19 Screw 2pcs
ST3.5*19 Screw 2pcs
To Next Page
