Asco 5101 - Start-Up Checklist

5101 Engine Start Monitoring System
381333-474 C 13
Setup Checklist
5101-ATS Module
Validate wiring: ATS engine start signal to TB1.
Validate wiring: 2-wire signal from TB2 to 5101-GEN module.
5101-Gen Module
Power up: check the module is receiving 24Vdc from the generator.
Validate wiring: Signals from 5101-ATS modules.
Validate wiring: Alarm signal to external device.
Validate wiring: Engine start signal to generator.
Configure DIP switches for specific needs
Check for correct LED status (all channels should be either blue or green in idle state)
