A.2 BS3x0 and DB1
Table 2 Power consumption (watts) of base stations and cabling when powered from the IPBL
Table 3
Cable
length
(metres)
0.4 mm
wire size
()
0.4 mm
wire size
()
0.5 mm
wire size
()
0.5 mm
wire size
()
0.6 mm
wire size
()
0.6 mm
wire size
()
Without
EPP
With
EPP
Without
EPP
With
EPP
Without
EPP
With
EPP
0 5.0 5.0 5.0 5.0 5.0 5.0
100 5.2 5.1 5.1 5.1 5.1 5.1
200 5.3 5.2 5.2 5.1 5.1 5.1
300 5.6 5.3 5.3 5.2 5.2 5.1
400 5.8 5.5 5.5 5.3 5.3 5.2
500 6.1 5.6 5.6 5.4 5.4 5.2
600 6.5 5.8 5.8 5.5 5.4 5.3
700 7.1 6.0 6.0 5.6 5.5 5.3
800 8.1 6.2 6.2 5.7 5.6 5.4
900 - 6.5 6.5 5.8 5.7 5.4
1000 - 6.9 6.9 5.9 5.8 5.5
1100 - 7.3 7.3 6.1 5.9 5.6
1200 - 8.1 8.1 6.2 6.1 5.6
1300 - - - 6.4 6.2 5.7
1400 - - - 6.6 6.4 5.8
1500 - - - 6.9 6.6 5.8
