ASCOM U952T User Manual

TD 90227GB
10 October 2013 / Ver. D
System Installation
Ascom Paging System
17
For several reasons an address register should be kept for each installation, with the name,
address, and location of each unit.
Address Register
0 0
0 1
0 2
0 3
0 4
T942C
T940PX
T840IU
T966CI
U952T
Attic, head office
Exchange room, head office
Exchange room, head office
Reception, head office
Beneath the roof, storeroom
Address (hex) Unit Location
Figure 10. Example of an address register.
When using sequential transmission, the sequence
number is set by sections 5-8 of the
address switch. The central transmitter always transmits in sequence 0 (address 00) and
the transmitters that are meant to transmit simultaneously should also have hex 0 as the
first digit in the address. Next sequence uses hex 1 as the first address digit and so on.
Each sequence can have up to 16 transmitters. Sequential transmission is used to avoid
interference between the transmitters but cannot be used in speech systems.
Address Register
0 0
0 1
0 2
0 3
0 4
1 0
2 0
T942C
T942PX
T840IU
T966CI
U952T
U952T
U952T
Attic, head office
Exchange room, head office
Exchange room, head office
Reception, head office
Beneath the roof, storeroom
Cellar, head office
Culvert, head office
Address (hex) Unit Location
Figure 11. Example of an address register in an installation with sequential
transmission.
9.1 Location Code
Setting the location code in a locator is done with the same type of dip switches as for
setting the address in a fixed unit. Two switches with a total of 16 sections are divided into
four hexadecimal digits. To set the location code, refer to the Installation Guide for the
relevant locator (LF or IR type).
