ascon A5LCX 10 C User Manual

130
MODEL : A5CMX 15/20/25E/ER
A5CMX15E A5CMX15ER A5CMX20E A5CMX20ER A5CMX25E A5CMX25ER
1 ASSY.,TOP PANEL CE-E R50124074907
√√√√√√
ASSY.,COIL INDOOR R50024085233
√√
ASSY.,COIL INDOOR R50024080385
√√
ASSY.,COIL INDOOR R50024071828
√√
3 ASSY.,VANE CE20/25/28E R50124074906
√√√√√√
ASSY.,INS DRAIN PAN CE E SERIES R50124076123
√√√
ASSY.,INS DRAIN PAN CE ER SERIES R50124080076
√√√
ASSY., CONTROL BOX (5)CEX15E R50044090153
√
ASSY., CONTROL BOX (5)CEX15ER R50044090154
√
ASSY., CONTROL BOX 5CEX20E R50044086799
√
ASSY., CONTROL BOX 5CEX20ER R50044086800
√
ASSY., CONTROL BOX 5CEX25E R50044086801
√
ASSY., CONTROL BOX 5CEX25ER R50044086802
√
6 COVER,TERMINAL BLOCK CE-E R12014071351
√√√√√√
MOTOR, MCE15E-501 40W HUATE R03034085800
√√
MOTOR, MCE20E-501 HUATE R03039023304
√√
MOTOR, MCE25E-501 HUATE R03039023305
√√
8 MOTOR, BRACKET CE E R01014071324
√√√√√√
9 BLOWER WHEEL, M506ZMCF L/R OYL R03024004754
√√√√√√
10 BLOWER HOUSING CE E R12014071385
√√√√√√
11 MOTOR, MP35EA HIGASHI FUJI/LEILI R03039023303
√√√√√√
12 ASSY., PANEL BOTTOM R50124085499
√√√√√√
STICKER, LED (ACSON COOLING) R08024076455
√√√
STICKER, LED (ACSON HEATING) R08024075060
√√√
14 COVER, HANGER L1(C) R12014071354
√√√√√√
15 COVER, HANGER L2(D) R12014071355
√√√√√√
16 COVER, HANGER R1(A) R12014071356
√√√√√√
17 COVER, HANGER R2(B) R12014071357
√√√√√√
18 BRACKET, MOUNTING CE E (FLOOR) R01014071319
√√√√√√
19 COVER, CONTROL BOX R01014069872
√√√√√√
20 CLAMP, WIRE CE E R12014071348
√√√√√√
HANDSET, WIRELESS G12EC W/IONIZER ACSON R04084065327
√√√
HANDSET, WIRELESS G12AP W/IONIZER ACSON R04084067315
√√√
CONTROL MODULE, 09A EC VA3 CEX 15 R04084086605
√
CONTROL MODULE, 09A AP VA3 CEX 15 R04084086606
√
CONTROL MODULE, 09A EC VA3 CEX 20 R04084086679
√
CONTROL MODULE, 09A AP VA3 CEX 20 R04084086607
√
CONTROL MODULE, 09A EC VA3 CEX 25 R04084086680
√
CONTROL MODULE, 09A AP VA3 CEX 25 R04084086608
√
INTAKE GRILLE CE E R12014071341
√√√√√√
COVER, BACK CE E R12014073883
√√√√√√
Parts not in diagram
DESCRIPTION PART NUMBER
RELATED MODEL
7
No
2
4
5
13
