m. The device TVR Y, directly supplied by the instrument, it allows
to visualize the temperature measured by the probe Pr1 through a
2 ½ digit display.
SUPPLY
TVR Y
cable 10 m MAX.
For additional info, please have a look at the TVR Y instruction
manual.
4.7.3 - RS 485 SERIAL INTERFACE BY “TLCNV”
The instrument can be connected by a special cable to the TLCNV
device (mod. C - TTL/RS485 interface), by means of which it is
possible to connect the regulator with a net to which other
instruments (regulators of PLC) are connected, all depending
typically on a personal computer used as plant supervisor.
Using a personal computer it is possible to acquire all the function
information and to program all the instrument’s configuration
parameters.
The software protocol adopted for the instrument is a MODBUS
RTU type, widely used in several PLC and supervision programs
available on the market (Y and Z series protocol manual is
available on request).
If the instrument is used with TLCNV program by the parameter
"t.Ad" the station Address.
Set a different number for each station, from 1 to 255.
Note: The baud-rate are fixed at 9600 baud.
TLCNV interface is directly supplied by the instrument.
SUPPLY
TLCNV
cable
654
879
ON
321
TX/RX
TTL
TLCNV
BGND A
RS 485
For additional info, please have a look at the TLCNV instruction
manual.
5 - PROGRAMMABLE PARAMETERS TABLE
Here below is a description of all the parameters available on the
instrument. Some of them may not be present because depend
on the model/type of instrument.
0.0-30.0 ÷ 30.0Probe Calibration
i.C1
7
2.0oF ÷ 20.0
sec
Measurement filter
i.Ft
6
C1C0 / F0 / C1 /
F1
Unit of measurement
and resolution
(decimal point)
C0 = °C with 1° res.
F0 = °F with 1° res.
C1 = °C with 0.1° res.
F1 = °F with 0.1° res.
i.uP
5
ntPt / ntProbes Type
i.SE
4
i. - parameters relative to inputs
0.0LS ÷ HSSet Point
SP
3
99.9LS ÷ 999Maximum Set Point
S.HS
2
-50.0-99.9 ÷ HSMinimum Set Point
S.LS
1
S. - parameters relative to Set Point
NoteDef.RangeDescriptionPar.
oFoF/ 0.01 ÷ 9.59
(min.sec ) ÷
99.5
(min.sec.x10)
Temperature Alarms
delay
A.At
24
1.00.0 ÷ 30.0
°C/°F
Temperature Alarms
Differential
A.Ad
23
oFoF / -99.9 ÷
999 °C/°F
Low temperature
Alarm threshold
A.LA
22
oFoF / -99.9 ÷
999 °C/°F
High temperature
Alarm threshold
A.HA
21
11 / 2
(/ 3 / 4 / 5 / 6 /
7 / 8 = don’t
use)
Temperature alarms
Type:
1 = Absolute
2 =Relative to Set
A.Ay
20
A. - parameters relative to alarms
oFoF/ 0.01 ÷ 9.59
(min.sec ) ÷
99.5
(min.sec.x10)
Delay at power on
P.od
19
oFoF/ 0.01 ÷ 9.59
(min.sec ) ÷
99.5
(min.sec.x10)
Out delay between
switching-on
P.P3
18
oFoF/ 0.01 ÷ 9.59
(min.sec ) ÷
99.5
(min.sec.x10)
Out delay after switch
off
P.P2
17
oFoF/ 0.01 ÷ 9.59
(min.sec ) ÷
99.5
(min.sec.x10)
Out delay at switch on
P.P1
16
P. parameters relative to compressor protection and power
on delay
oFoF - on - LbDefrost display Lock
oF= display free
on= Lock on
temperature Pr1
before defrost
Lb= Lock on label
“dEF” (during
defrosting) and “PdF”
(during
post-defrosting)
d.dL
15
oFoF/ 0.01 ÷ 9.59
(min.sec ) ÷
99.5
(min.sec.x10)
Lenght of defrost cycle
d.dE
14
oFoF/ 0.01 ÷ 9.59
(min.sec ) ÷
99.5
(min.sec.x10)
Delay first defrost after
power-on
(oF = Defrost at
power-on)
d.Sd
13
oFoF/ 0.01 ÷ 9.59
(hrs.min. ) ÷
99.5
(hrs.min.x10)
Defrosting interval
d.di
12
d. - parameters relative to defrosting control
CH - COutput operating mode
H= Heating
C= Cooling
r.HC
11
oFoF/ 0.01 ÷ 9.59
(min.sec ) ÷
99.5
(min.sec.x10)
Output deactivation
time for probe error
r.t2
10
oFoF/ 0.01 ÷ 9.59
(min.sec ) ÷
99.5
(min.sec.x10)
Output activation time
for probe error
r.t1
9
2.00.0 ÷ 30.0
°C/°F
Differential
(Hysteresis)
r.d
8
r. - parameters relative to temperature control
°C/°F
ASCON TECNOLOGIC - Z31- -OPERATING INSTRUCTIONS- Vr. 02 - 03/12 - ISTR-MZ31-ENG02 - PAG. 6
