E:Connectingtoanexternaldecoderorapoweramplifier
When DVD discs recorded in Dolby digital, MPEG audio or other formats are played, corresponding bit
stream is output from the player s COAXIAL digital audio output connector. When the player is
connected to an external decoder or a power amplifier, you can enjoy quality of theatre level at
your home!
,
CD
DVD
MP3
Sound
recording format
Dolbydigital
DTS
LinearPCM
Other
MP3
LinearPCM
Digitaloutputsetting
PCM(44.1KHZ sampling)*1
Raw
OFF
Raw
OFF
PCM(44.1KHZ sampling)
PCM(44.1KHZ sampling)
PCM(44.1KHZ sampling)
PCM(44.1KHZ sampling)
*1soundhaving192KHzsamplingisconvertedto
48KHzsamplingwhenitisoutputfromtheCoaxial
digitalaudiooutputconnector.
Pleasereferto thesetupoperationsforsetup
method.
Note:
Foryourreference:
Cautionforthecoaxialaudiooutputconnector.
DolbyDigital(AC-3),adigitalsoundcompression
techniquedevelopedbytheDolbyLaboratories
LicensingCorporationsupports5.1-channelsurround
outputandstereosoundsystemenablesthecapacity
ofmassstoragerecordedindiscsLinearPCMisa
signal-recordingformatusedinCDsWhileCDsare
recordedin44.1KHz/16bit,DVDsare48KHz/16bit
upto192KHz/24bit.
Donotconnectanamplifier(withanCoaxialdigital
inputconnector)whichdoesnotcontaintheDolby
Digital(AC-3)orMPEGaudiodecoder,otherwiseit
maybeharmfultoyourearsanddamageyour
speakersChooseRAWinthedigitalaudiosetup
toactivatecoaxialoropticaloutputwhenplayingdisc
withDTSoutput.
BASICCONNECTION
DVDPLAYER
10
EuroSCART
(optional)
TVset(optional)
S-Videocord
(optional)
Video/audio
(optional)
DVD/CDplayer
Coaxialaudio
cord
Decoderof
amplifierwith
Dolbydigital
(AC-3)orMPEG
(optional)
Y
L
Pb/Cb
R COAXIAL
Pr/Cr VIDEO
S-VIDEO
SCART OUT
~100 -240V
50/6 0Hz
