BASICCONNECTION
Ensurethatthepowerswitchofthisunitand
otherequipmenttobeconnectedisturnedoff
beforecommencingconnection.
Readthroughtheinstructionsbeforeconnecting
otherequipment.
Ensurethatyouobservethecolour-coding
whenconnectingaudioandvideocords.
A:ConnectingtoastereoTVset
1. TVset(optional)
2.DVD/CDplayer
3.ConnectingVideo,R/L audiocords
4. To TVsetaudioinputconnector
5.ConnectingcordtoScartjack(option)
6.ToScartjack
Togetthebestviewingqualityyouareadvisedto
useS-videocordtoconnectthe TVsetwithS-video
inputandtochangethe TVsettoS-videoinputmode.
B:ConnectiontomonophonicTV
1. TVset(optional)
2.DVD/CDplayer
3. Audiocords
4. To TVsetaudioinputconnector
5. To TVsetvideoinputconnector
6.Componentconnectorcord(optional)
7.To TVcomponent(Y,Pb/Cb,Pr/Cr)inputconnector
C:Connectiontoaudioequipment
1. Audioplayer(optional)
2. TVset(optional)
3.DVD/CDplayers
4.Video/audiocords
5. To TVvideoinputconnector(yellow)
6. Toaudio inputconnectors(red,white)
7. To TVS-videoinputconnector
DVDPLAYER
1
B
1
A
7
1
2
C
3
4
4
3
5
7
6
5
6
4
2
~100 -240V
50/6 0Hz
~100 -240V
50/6 0Hz
2
3
Y
L
Pb/Cb
R COAXIAL
Pr/Cr VIDEO
S-VIDEO
SCART OUT
Y
L
Pb/Cb
R COAXIAL
Pr/Cr VIDEO
S-VIDEO
SCART OUT
Y
L
Pb/Cb
R COAXIAL
Pr/Cr VIDEO
S-VIDEO
SCART OUT
~100 -240V
50/6 0Hz
5
6
