Ashcroft 2074 - DIGITAL INDUSTRIAL GAUGE RANGES; DISPLAY MESSAGES AND ACTIONS

– 17 –
DISPLAY MESSAGES:
Display/Problem Description Action
No Battery Icon
Display (applicable to
gauges with batteries
Gauge has <10%
battery life left
Replace batteries
OFSET (blinking)
Zero/Clear button
pushed when pressure
displayed is beyond set
rezero pressure limit
Only rezero the gauge within
limits of setting in Menu
Menu button disabled
Gauge is in
Max/Min mode
Push Max/Min button until
unit of measure is displayed
on keypad
Unit of measure
selected in Menu
displays N/A
Resolution at full scale
pressure range
exceeds 50,000 counts
Choose another unit of
measure
I can’t access items in
the main Menu
Items that cannot be
accessed have been
disabled
Enable item(s) in the Menu.
See Menu/CONFIG and
diSAb or DISABLE
I can’t set the
password I want
00000 is not a valid
password
Select a different password
in.Hg Comp. mmHg in.Hg in. ft. Bar/
psi
(vacuum) (psi) (pressure) (pressure) H
2
O
mBar
H
2
O
mPa kPa
KSC
15 30 –15/0/15 800 30 400 1000 60 1 100 1
30 –15/0/30 1000 60 800 1500 160 1.6 160 1.6
60 –15/0/60 2000 100 1000 2000 200 2.5 250 2.5
100 –15/0/100 3000 160 2500 300 4 400 4
160 5000 200 4000 400 6 600 6
200 10,000 300 5000 600 10 1000 10
300 400 6000 1000 16 1600 16
600 600 10,000 25 2500 25
800 800 15,000 40 4000 40
1000 20,000 60 6000 60
1500 100 10,000 100
2000 140 16,000 160
3000 25,000 250
5000 40,000 400
8000 60,000 600
10,000 100,000 1000
15,000 140,000 1400
20,000
DIGITAL INDUSTRIAL GAUGE RANGES
Note: Rows listed are not the equivalent of each other.
