4.00
1.860
.17
HOLE
CUTOUT
DIAMETER
3.406
(3
13
⁄
32
±
1
⁄
32
)
3˝ CASE
PANEL MOUNTING DIMENSIONS:
CLAMPING RING (1278G ONLY)
WASHER
SPACER POST
(3 REQ’D)
“B” (3 REQ’D)
PANEL
MOUNTING
RING
6˝ RING
DIA.
5.65˝
PANEL
OPENING
5/16˝ MAX PANEL
THICKNESS
4
1
⁄2˝ CASE
Notes:
1) Do not mix ages or brands of batteries.
2) Do not replace batteries in hazardous areas.
3) To provide maximum battery life, replace both batteries
4) To provide maximum battery life, replace both batteries.
Pipe to which gauge is attached must be properly
grounded.
