EN 12
INSTALLATION
Building in dimensions
Assembly
• Remove the grease filters.
• Make an opening underneath one of the kitchen cupboards. Check
the dimensions on the installation drawing.
• Screw the hood into the kitchen cabinet with 4 screws.
