Asko CC4520 - Grease Filters; Carbon Filter; Lighting

EN 9
Grease filters
Removing the grease filters
• Move lock ‘C’ in a downward direction and remove filter ‘G’ from
the hood.
Carbon filter
Replacing the carbon filter
The carbon filter must always be used if the cooker hood is not ducted.
1. Remove the grease filters ‘G’.
2. Attach the carbon filters ‘J’ by hooking the brackets ‘K’ in the
openings.
3. Replace the grease filters ‘G’.
Note:
• Saturation of the activated charcoal will eventually occur after
prolonged use, depending on the type of cooking and how
frequently the grease filter is cleaned.
• The carbon filter needs to be replaced at least every four months.
• The carbon filter cannot be washed for reuse. Saturated carbon is
not environmentally friendly. Change the filter regularly.
Lighting
Changing the light bulbs
• Remove the lamp cover.
• Replace the halogen light bulb with a replacement bulb with a
maximum output power of 20 Watts.
• Re-close the lamp cover.
MAINTENANCE
