1. Pull out the upper basket, and the centre
basket if present, and turn the basket stop
on the runner outwards.
2. Remove the upper basket, and the centre
basket if present, by pulling the basket(s)
out as far as possible. This is to make more
space available during installation.
3. Remove the lower basket. Otherwise it
easily rolls out if you need to adjust the
dishwasher during installation.
4. Screw the dishwasher to the worktop from
the inside or to the cabinets on either side.
If the worktop is a hard material, such as
marble, screw the dishwasher to the side
cabinets. Use the supplied plastic spacers
when screwing the dishwasher into place!
Securing to worktop
Securing to side cabinets
Step 6. Securing the dishwasher
