Asko D5436 User Manual

Adjusting the plinth (only when using
toe kick accessory)
The dishwasher is supplied with one or two toe kicks depending
on the model. The table shows which toe kick you should use
depending on the recess height and plinth depth.
Plinth depth (mm)Recess height (mm)
10090807060504030
LLLN/AN/AN/AN/AN/A820
LLLLN/AN/AN/AN/A830
LLLLLLLL840
HHHN/AN/AN/AN/AN/A850
HHHHN/AN/AN/AN/A860
HHHHHHHH870
702602700457700456Low toe kick
(height=90 mm)
L
702603700441700440High toe kick
(height=120 mm)
H
Not recommended for aesthetic reasons.N/A
Recess height
Plinth depth
Set the correct plinth depth as follows
(Not applicable to all models)*
1.
2.
3.
21

Asko D5436 Specifications

General

Type	Freestanding
Energy Efficiency Class	A++
Number of Wash Programs	7
Installation	Freestanding
Delay Start	Yes
Child Lock	Yes
Drying System	Turbo Drying
Size	Standard
