Removing the inner glass pane (only applies to models in
which the inner surface of the door is made entirely of glass)
Door glass panes can also be cleaned from the inside; however,
they must fi rst be removed as follows:
• Remove the oven door (see section on removing and inserting
the oven door).
• Hold the inner glass pane of the door by its lower edge. Pull it
gently towards yourself and lift it slightly – but not too far – by
a maximum of 10 mm, until the glass support wedge slips out
of the groove (Figure 1).
• Remove the glass (in the direction of arrow 3).
• Remove the middle (second) and third glass pane by fi rst
undoing the screws on the glass supports and then by lifting it
(Figure 2). Before cleaning, remove the supports.
• Reinstall the door by following the same procedure in reverse
order.
Note: Insert the glass into the slot and push it forward
(Figure 3).
The inner door glass is treated with a special refl ective
fi lm. Only use a mild detergent (soapsuds) and a soft
non-abrasive sponge to clean the surface. Do not use
any harsh or abrasive detergents or cleaning aids that
contain solvents.
REMOVING AND REPLACING THE OVEN DOOR WITH A
SINGLE-AXIS HINGE (depending on the model)
a) Conventional closing
b) GentleClose – the system absorbs the shock from door
closing. It allows simple, quiet, and smooth closing. A gentle
push (to a 15° angle relative to the closed door position) is
enough for the door to close automatically and softly.
If the force applied to close the door is too strong, the
effect of the GentleClose system is reduced or the
system will be bypassed for safety.
• Fully open the oven door and rotate the stoppers all the way
back – applies to conventional door closing (Figure 1).
fi gure 2
fi gure 3
fi gure 1
fi gure 1
37
