14
The following conditions apply for the consumption values indicated below:
Temperature of intake air: 20ºC
Humidity of intake air: 65%
Drying temperature: Normal (
),Low ( )
Element power: 2500 W
Cotton fabrics spin-dried, prior to tumble drying, at 800 and 1600 revs per minute (low spin) in
ASKO washing machine.
Other fabrics (non-iron and acrylic) spin-dried, prior to tumble drying, at 800 revs per minute (short
spin) in ASKO washing machine.
7 CONSUMPTION VALUES
MATERIAL LOAD POWERCONSUMPTION RECOMMENDED PROGR.
(approx. kWh) TIME (approx. minutes)
800 rpm - 1600 rpm 800 rpm - 1600 rpm
Cotton, linen, 1/1 (5.0 kg) 3.1 - 2.4 84 - 66
Non-iron, polyester/ 1/2 (2.5kg) 1.2 --- 30 ---
cotton,
Acrylic, rayon, 1/2 (2.5 kg) 1.7 --- 114 ---
acetate,
