Asko W600 Service Manual

Model W600 (WM-33)
Page
Description
Fig
. Part No.
Notes
Date
2000-02
Qty
11CYLINDER AND RELATED PARTS
1 1 8061650-0 Front door compl., white WM20
1 8061651-0 Frame, front door, outer, white WM20
1 8061652-0 Frame, front door, inner, white WM20
1 8061685 Front glass D306x42mm, WM20
1 8061798 Lock hook WM20
1 8061653 Seal, front door
4 8061624 Securing plate, front glass
1 8061686-0 Hinge, front door, white WM20
1 8061687 Shaft for himge WM20
2 8901969 Screw MRT-TT 5x12 FZB T25
11 1 8061671-0 Cover plate, outer, white
13 1 8061980 Gap sealing, lower WM20
14 2 8061616 Gap sealing, side WM20
15 1 8061670 Cover plate, inner
16 2 8061678 Damper weight
3 8901135 Screw M6SF-TT 8x25, DRILOC, FZB
18 1 8061679 Door lock WM20
19 1 8061780 Emergency opening, compl. WM20
20 1 8061680-UL Contact guard, door lock WM20
21 1 8061677 Front panel, tub WM20
22 1 8061889 Sealing strip, front panel (tub)
23 1 8061669 Tension ring WM20
1 8901335 Washer BRB 6.4x12 HB 200 Galv.
1 8901154 Nut M6 BH8, Galv.
1 8901116 Screw MC6S 6x85, 8.8 FZB
25 1 8061600 Cylinder, compl. WM20
26 3 8061604 Drum paddle WM20
27 1 8061682 Drive belt 5EPJ 1209
28 1 8058497 O-Ring 26.2x3 NBR70, DW95
29 1 8061638 V-ring cassette, compl.
30 2 8056314 Ball bearing 6206 2RS MTSRL
31 1 8801165 Container compl. WM20
32 1 8056810 Scale washer 37x30.5x0.5
33 1 8056376 Pulley, compl. D292
1 8057209 Washer 42x10x4
1 8901052 Screw BUFO 8.8, 10s25, galv.
