SERVICE
I N F O R M A T I O N
Product: Frontloaded
Date: 00-06-14
Reference:Bo Fredriksson
Group: 21
Number: 158
ÄO: 7782 Page: 1(1)
Front door seal
WM 33/44/55
Placement of O-ring
Figur 1
Service intervention for leaking front door.
First verify that the door seal is not damaged or covered by lose particles.
In order to increase the sealing strip pressure against the sealing surface of the container, a special O-
ring (part no. 8064178) has been designed.
As of Week 19, 2000, the front door O-ring is factory installed on all WMC 55 Professional models.
The front door O-ring can be fitted on earlier WMC 55 models as well as on WMC 33-44-55-66 to
remedy a leaking front door seal.
Fitting the front door O-ring, part no. 8064178
Fit the O-ring by placing it on the outside, covering the sealing strip (see picture) between the plastic
part of the door and the sealing strip. See the figure.
