Model W600 (WM-33)
Page
Description
Fig
. Part No.
Notes
Date
2000-02
Qty
7CASING AND RELATED PARTS
1 1 8061817-0 Top Cover, white
3 8900338 Screw RTK STt 4.2x9.5 FZB T20
2 8901413 Lock washer AZ 4.3 galv.
3 1 8064062 Strip, top cover WMD20
6 1 8801174-0 Side plate compl. WM20
7 2 8061763 Guide, front plate/top cover
8 3 8061916 Cable holder WMD20
9 2 8061713 Holder hose, side plate
10 2 8061623 Plastic bracket, front plate/2
11 1 8064017 Sound insulation, outlet hose
12 1 8063925-0 Front plate compl., white WM20
2 8900327 Screw RTS ST 4.2x13 FZB T20
14 2 8063371 Guide, front plate
23 1 8061657-0 Door outlet pump WM20
27 1 8061737 Rear panel WM20
8 8900338 Screw RTK ST 4.2x9.5 FZB T20
31 1 8061693 Transport Beam
1 8901413 Lock washer AZ 4.3 galv.
4 8900338 Screw RTK ST 4.2x9.5 FZB T20
33 3 8061735-UL Transport sleeve WM20
34 3 8901940 Screw M6S M8x70 FZB w/guide
35 3 8061767 Locking washer, transport beam WM20
36 2 8061799 Holder hose, rear panel
37 1 8056950 Connection pipe W-1500-15-3/4"-3/
