Asko W600 Service Manual

Model W600 (WM-33)
Page
Description
Fig
. Part No.
Notes
Date
2000-02
Qty
9LOWER SECTION
1 1 8801171 Spring leg kit WM20
2 4 8055796 Rubber buffer, spring leg
3 4 8055797 Rubber buffer, spring leg
4 4 8061668 Rubber Damper, spring leg
4 33256445 Washer, spring leg 37x37x2
4 8901193 Locking nut 8 BHB galv.
6 8901343 Washer SRKB 11x28x2 FZB
6 1 8061772 Motor 60 Hz WM33/44
7 2 8058261 Spac. tube motor suspension 12x191
8 2 8063591 Screw 8.8 M8x205 FZB
1 8901337 Washer BRB 8.4x16 HB 200 galv.
2 8901155 Nut M6M8 BH8, galv.
10 1 8086801 Cable set E60-MO WM44/33 (P)
15 1 8061681 Bellows hose outlet pump WM20
16 1 8063262 Hose clip 80.0-708
17 1 8056471 Hose clip
18 1 8052083 Hose clip RFZ 39.6-706R
19 1 8061924 Pressure chamber WM20
20 1 7382670 Rubber hose 5x8x550
21 1 8801167 Drain pump sync. han. compl. WM20
22 2 8061649 Rubber buffer, drain pump WM20
23 1 8061796 Rubber ring, drain pump WM20
24 1 8061725 Drain hose 180mm, WM20
1 8052731 Hose clip OETIKER 14.8-706R
26 1 8061998 Outlet hose WM20
1 8056491 Hose clip 30.1-708
28 1 33700183 Terminal ESPA
1 8901097 Screw MRT-11 rx12 FZB T20
1 8901413 Lock washer AZ 4.3 galv.
30 1 8061738 Thermistor holder WM20
31 1 8061663 Thermistor (E30)
2 8061976 Cable holder, small
1 8054485 Cable strip T50R SF/PH
34 1 8061674 Recirculation stub
35 1 8061673 Grommet, recirc. stub
36 1 8061945 Hose, recirculation curved 345 mm
38 3 8054196 Hose clip FZB 22.8-25.6
40 1 8061706 Heating element 2000W, 230V
1 33700450 Cable strip T 30 R
