Installation
Built-in installation
ASKO washers can be installed beneath a
cabinet or worktop with a height of 34" to 35"
(863 to 889 mm) or in a closet. There must be a
gap of about ½" (12 mm) all around the machine,
including between the rear edge of the machine's
top panel and the back wall. The opening width
must be at least 24½" (622 mm). Space must
also be available for the ll and drain hoses. See
the illustration below for measurements and
positions. If the washer is installed in a closet
the door must be left open while the washer is
running.
If the drain outlet is higher than 24"(610 mm), the
connections will need to be recessed.
