Before the machine is used, the three
transport protection devices should be
removed as shown below.
Each transport protection device consists of
a screw, a washer and a rubber spacer. After
the protection device has been removed, the
rubber spacer acts as a plug for the holes for
the device and also as a damper.
• First remove the screws and remove the
washers.
• Then remove the rubber spacers.
• Finally, the rubber spacers should be
turned over and replaced in the transport
protection device holes.
Important!
In order to prevent the machine from being
damaged when it is transported, use the
transport protection device, which locks the
entire inner compartment in place. If the
transport protection device is missing, you
can order one from your retailer.
Item number:
8901037 Bolt
8061767 Washer
Order three of each item!
22
Transport protection
