Asko W6342 - Washing Machine Components; Detergent Compartment Details

1
2 3
4
8
7
5,6
1.
Detergent compartment
2.
Main power switch
3.
Program panel
4.
Serial Number
5.
Hatch - drainage pump
6.
Drainage pump (behind hatch)
7.
Washer door
8.
Outer door (not all models)
Detergent compartment
1
3
2
1.
Detergent compartment - pre-wash
2.
Detergent compartment - main wash
3.
Fabric softener compartment
In the plastic bag containing these instructions and other things, you will find a plastic divider.
Place the divider in the detergent compartment if you use liquid detergent.
7
Description of the washing machine
