Built-in installation
ASKO washers can be installed beneath a
cabinet or worktop with a height of 34½" (876
mm). There must be a gap of about ½" (12
mm) all around the machine, including be-
tween the rear edge of the machine's top
panel and the back wall. The opening width
must be at least 24½" (622 mm). Space must
also be available for the inlet and drain hoses.
See the illustration below for measurements
and positions.
If the drain outlet is higher than 24"(610 mm),
the connections will need to be recessed.
Customer Care Center36
1-800-898-1879
www.askousa.com
Installation instructions
