Service manual WM25
14
Item number Component Measurement value Comments
80 616 64 Pressure sensor 0.5 V out from the
sensor (at 0 bar pres-
sure and 230 V mains
voltage, measurement
carried out with the
drain pump running
to ensure 0 level is
reached)
ASKO level sensor type 1166. Controls
intake and level
80 762 02 EMC filter with induc-
tor 50/60 Hz
The filter eliminates interference to and
from the machine.
80 762 01 Inlet valve 3,7 k
Ω ± 0.5 kΩ 3 way inlet valve 10 litres / minute
80 616 79 Door lock 122
Ω The door lock is electro mechanical
and equipped with a magnet.
80 771 27 Control Unit WM25.1
80 771 28 Control Unit WM25.2
80 771 29 Control Unit WM25.3
80 803 88 Control Unit WM25.3
CIM
80 822 58
Frequency motor
control
