Service manual WM25
15
Technical data
Height: 850 mm
Width: 595 mm
Depth: 585 mm
Weight: 73 kg / 78 kg (with outer door)
Cylinder volume: 50 l
Max. washing capacity: 6.0 kg
Spin speed max: 800/1400 rpm
Spin speed max: CIM motor max 800/1600 rpm
Connection: 1 phase 10 A
Element power: See type plate.
Water pressure: 0,1 1 MPa., 1 10 kp/cm², 10 100 N/cm²
Wash drum and liquid compartment material: Stainless steel
Outer casing material: Powder-coated and hot-galvanized sheet steel or
stainless steel
Set-up: Stationary on four adjustable, rubber-clad feet
Water connection: 1.5 m PEX tubing, 3/4” – 3/4” or 3/4” – 1/2”
Drain: 1.7 m polypropylene tubing
Protection class: IP X4
