Page #15 background imageLoading...
Page #15 background image
VAR8 / Variants - Installation Guide
Audio Monitoring Bus and Auxiliary Supply
Signal Description
V+ Auxiliary supply: 18V-36V fused at 200mA
A
Audio Monitor Bus, –10dBu nom
A+ As above
L Cabling connector: 3 way terminal block (METWAY 120A11103)
Power Supply
Signal Description
V+ +V supply (18V-40V DC fused at 2.5A)
GND 0V supply
L Cabling connector: 4 way terminal block (METWAY 120A11104)
Issue: 01 complete, approved
Page 15 of 22
