Standard Compliance
• Homeplug
®
power line v1.01
• Windows
®
98 SE, 2000, ME
& XP Compatible
• IEEE 802.3
Protocol
TCP/IP
Interface
USB (B Type)/ ETH (RJ-45)
S
peed
Up to 14Mbps
Cabling T
ype
• USB / Ethernet cable
LED S
tatus Lights
USB: COL, LNK, ACT
ETH: COL, LNK, ACT,
ETH-LNK/ACT
Environment
al:
Dimensions (LxWxH)
USB 7.5x4.75x2.5cm
ETH 9.5x6.5x4cm
USB Cable (L) / Ethernet
6’
Weight
USB 0.25 lbs
ETH 0.50 lbs
Power Input
110V AC, 5W
Safety & EMI
FCC part 15,
UL (US and Canada)
Operating Temperature
32°F to 131°F (0°C to 55°C)
Storage Temperature
-4°F to 158°F (-20°C to 70°C)
Operating Humidity
10% to 85% Non-condensing
Storage Humidity
5% to 90% Non-condensing
Appendix A
Specifications
Asoka™ PlugLink™ Wall Mount Users Manual
22
