The combustion air intake grille must locate in a well-ventilated place. To prevent corrosion, it is necessary
that the combustion air is free of aggressive substances. Aggressive substances are halogenated hydrocarbons
which contain chlorine or fluorine. These substances are found in solvents, paints, adhesives, gasses or
liquid-propellants and household cleaners. If these conditions are not able to guarantee, another place
should be chosen for the air intake.
3. UNIT INSTALLATION
8
3.3 Installation Modes
2.4 Internal wire Diagram
Induction Pin Connection
Water Flow Sensor Connection
Ignition Pin Conncetion
Switch Valve Connection
Switch Valve Connection
Gas Proportional Valve Connection
Grounding Wire
Display
Power Connection
AC-Motor Connection
Transfomer
To Next Page
