8
1. Place the wheelchair on
levelled ground. Then, push
both legrests down and
click into place, so that the
locking bracket hugs the
aluminium tubing.
2. Pushdown on the side rails
of the seat until flat.
3. Flip up and click backrest
into place.
IMPORTANT: Ensure your
fingers are keep clear from
the pivoting mechanism.
6 . A SSE M B LY
Wheelchair frame fitted with rear wheels
i) 14 inch (Metro - Attendant Propelled) OR
20 inch (Metro and MetroX - Self Propelled).
ii) User Manual
*MetroX - Self Propelled model shown in instructional images
1
When opening the carton, ensure it is done in a safe
and careful manner. DO NOT USE a box cutter or sharp
implement as this may damage the product. For WH&S
purposes, lay the carton on its side with the top of the
carton open and slide the plastic bag out containing the
wheelchair.
2
3
Aspire Metro Wheelchairs
Push
*CLICK*
Push
Flip up
*CLICK*
BOX CONTAINS:
To Next Page
