No. Description
1 PSU SMBus Header (PSU_SMB1)
2 ATX 12V Power Connector (ATX12V1)
3 ATX 12V Power Connector (ATX12V2)
4 ATX Power Connector (ATXPWR1)
5 USB 3.0 Header (USB3_3_4)
6 Rear Fan Connector (REAR_FAN1)
7 Rear Fan Connector (REAR_FAN2)
8 OCuLink x4 Connector (OCU1)
9 CPU Fan Connector (CPU1_FAN1)
10 Front Fan Connector (FRNT_FAN1)
11 OCuLink x4 Connector (OCU2)
12 M.2 Socket (M2_2) (Type 2230 / 2242 / 2260 / 2280 / 22110)
13 M.2 Socket (M2_1) (Type 2230 / 2242 / 2260 / 2280)
14 Mini-SAS HD Connector (SATA_0_3)
15 SATA SGPIO Header (SATA_SGPIO1)
16 Mini-SAS HD Connector (SATA_4_7)
17 Front Fan Connector (FRNT_FAN2)
18 Front Fan Connector (FRNT_FAN3)
19 Front Fan Connector (FRNT_FAN4)
20 Graphics 12V Power Connector (GFX_12V1)
21 Clear CMOS Pad (CLRMOS1)
22 Speaker Header (SPEAKER1)
23 System Panel Header (PANEL1)
24 Auxiliary Panel Header (AUX_PANEL1)
25 ermal Sensor Header (TR1)
26 TPM Header (TPMS1)
27 BMC SMBus Header (BMC_SMB_1)
28 Intelligent Platform Management Bus header (IPMB1)
29 Non Maskable Interrupt Button (NMI_BTN1)
30 Chassis ID3 Jumper (CHASSIS_ID3)
31 Chassis ID2 Jumper (CHASSIS_ID2)
32 Chassis ID1 Jumper (CHASSIS_ID1)
33 SATA DOM Power Jumper (SATAPWR1)
